imageRUNNER 2224N/2224

Machine Type

Core Functions

iR2224N: Print, Copy, Scan, and Send
iR2224: Print, Copy, and Scan

Control Panel

88.9-mm monochrome touch panel

Memory

1.0 GB RAM

Storage

eMMC: 2 GB

Interface Connection

NETWORK*1
Standard: 100Base-TX/10Base-T, Wireless LAN (IEEE 802.11 b/g/n)

OTHERS Standard:
USB 2.0 (Device) x1

Paper Supply Capacity (A4, 80 g/m2 (gsm)

Standard: 350 sheets (Paper Drawer: 250 sheets, MPT Tray: 100 sheets)
Maximum: 600 sheets (with Cassette Feeding Module-AK1)

Paper Output Capacity (A4, 80 g/m2 (gsm))

Standard: 250 sheets
Maximum: 250 sheets

Supported Media Types

Multi-purpose Tray:
Thin, Plain, Recycled, Thick, Colour, Bond, Label, Pre-punched, Envelope

Paper Cassette:
Plain, Recycled, Colour, Pre-punched

Supported Media Sizes

Multi-purpose tray:
A3, A4, A4R, A5, A5R, B4, B5, B5R,
Envelope (COM10, Monarch, DL, ISO-C5),
Custom size min. 95.0 x 148.0 mm up to 297.0 x 431.0 mm

Paper Cassette:
Standard size: A3, A4, A4R, A5R, B4, B5, B5R

Supported Media Weights

Multi-purpose tray: 60 to 157 g/m2 (gsm)
Paper cassettes: 64 to 90 g/m2 (gsm)
Duplex: 60 to 90 g/m2 (gsm)

Warm-up Time

From Power On: 13 seconds or less*2 *3
From Sleep Mode: 4.3 seconds or less

Dimensions (W x D x H)

iR2224N (with DADF): 627 x 607 x 606 mm　 iR2224/2224N (with Platen cover): 627 x 589 x 502 mm
iR2224N (with DADF and cassette): 627 x 607 x 698 mm　
iR2224N (with Platen cover and cassette): 627 x 589 x 594 mm

Installation Space (W x D)

1065 x1285 mm

Weight

iR2224N: Approx. 30.3 kg without toner and Platen cover
iR2224: Approx. 31.6 kg without toner and including Platen cover
